Nucleic Acid Extraction System (NFAST 96)

Nucleic Acid Extractor(NFAST 96) is an automated nucleic acid extraction instrument based on nano magnetic bead purification technology, which integrates lysis, wash and elution.

The Advantage of Product

H i g h q u a l i t y
a n d r a p i d e x t r a c t i o n

13min/96 samples.

M u l t i p l e
p o l l u t i o n c o n t r o l

Deep-well plates are used to control interhole contamination, UV disinfection avoids pollution in different batches.

I n t e l l i g e n t
o p e r a t i o n

start-on self-inspection, power-off protection, Temperature control accurately, High temperature warning, Sample protection, etc.

H i g h - t h r o u g h p u t

Fully automated operation, High-throughput.

Performance Parameter

Parameter

Contents

Specimen

Saliva samples, sputum, nasopharyngeal swabs, oropharyngeal swabs,blood serum and plasma

Sample volume

30~1000ul

Throughput

1~96 samples

Recovery rate of magnetic beads

>99%

Operation time

96 samples synchronous extraction in 13 minutes

Plate position

Precision

CV < 3%

Consumables

96 deep-well plates + 96 magnetic bar sleeves

Mixing modes

Multi-speed adjustable

Thermal range

Room temperature ~ 120°C adjustable

Operation interfac

Android operating system with 10-inch color LCD display and touch screen

Data storage

> 500 protocols

Program management

New, edit, delete and save; U disk import program

Low noise processing

Noise≤50db

Preheating function

With preheating function, fast heating speed

Pollution control

HEPA filter system and UV lamp

Operational environment

Temperature 5-40°C; Humidity≤80%

Dimension

Dimension: 545mm*610mm* 510mm (it in biosafety cabinet); Weight:50kg

Others

Built-in lighting: Scan code operation can be set up (optional); USB interface; Can expand the Ethernet
