Parameter

Contents

Instrument model

Gis-1000

Instrument function

It has the functions of automatic scanning, automatic focusing, tag filtering and output report

Software function

Software AI interpretation, database support remote iterative update

Recognition ability

It can simultaneously identify epithelial cells, white blood cells, red blood cells, sperm cells, lactobacillus, gonococcus, streptococcus, fungi, spores, hyphae, clue cells, trichomonas and other tangible components, and can conduct artificial intelligence interpretation of bacterial density, bacterial diversity, cleanliness, etc

Operation interface

LCD 10-inch touch screen

Operation system

Linux

Scan speed

25 pictures/slide, 80 seconds/slide

Scanning accuracy

0.267um/pixel, error ± 5%

Throughput

1 slide

Intelligent control

Running after intelligent identification of logo

Scan code

Support barcode and QR code, automatically enter sample information

Imaging modules

Gis-1000 has a blue light module, and Gis-1100 is a purple light module

Size

313*278.5*366.9mm

Net weight

10kg
